Description
A compact 3A MotorController for automated comfort ventilation in a single room or zone. It opens and closes ±24V DC window actuators from comfort keypads, room and weather sensors – and, on the ‘A’ version, wirelessly via the WCA 100 remote or the Fresh Air Control app. Ideal for classrooms, meeting rooms and smaller offices.
Key Features:
– Natural / comfort ventilation for one room or zone
– Controls ±24V DC standard actuators – 3A, one motor line
– Wireless open / stop / close via WCA 100 remote control or Fresh Air Control app
– Accepts room sensors, weather sensors, comfort keypads and BMS signals
– Up to 10 MotorControllers can be linked and share one weather station
– DIP switch configuration
– Also available as the WCC 103 (without wireless and app control)
Specifications:
Output Current: 3A | Output Voltage: 24V DC (±15%) | Primary Voltage: 100-240 VAC 0.85A 50/60Hz | Ventilation Groups: 1 | Motor Lines: 1 motor line | IP Rating: IP 20 | Housing: Plastic housing for surface mounting | Size: 206 x 215 x 37 (H x W x D)mm | Colour: White (RAL 9016)
Delivery includes: MotorController. WCA 100 remote control ordered separately if required. Supplied, installed and commissioned Australia-wide by Blue Squared, the exclusive Australian WindowMaster partner.
Specifying the WCC 103 A for a project?
Blue Squared is the exclusive Australian partner for WindowMaster. Send us your drawings or window schedule and our team will recommend the right actuators and controls, design the system and quote supply, installation and commissioning. We aim to respond within 48 hours.
Get a Free System Design & QuoteRequest BIM / CAD Files
Prefer to talk it through? Call 1300 85 12 12 – Sydney, Melbourne, Brisbane and Adelaide.
↓ Download Product Sheet – WCC 103 A
↓ Download Product Sheet – WCC 103
